Why semiconductors are central to geopolitics and where India stands in the power matrix

India began its semiconductor journey in the 1970s. How advanced is indigenous manufacturing now?

WrittenBy:Priyank Shukla
Date:
Article image
  • Share this article on whatsapp

With India’s recent objection to the American CHIPS Act at the World Trade Organisation, the focus is back on the economic, technological and geopolitical significance of the semiconductor industry.

The US law, ostensibly aimed at tackling the China “threat”, was criticised by the Indian government for restricting equal access to technology. And it wasn’t the first such episode hinting at the geopolitical vitality of semiconductors: the US had earlier cut off chip supplies to Russia and subsequently banned the shipment of Nvidia and AMD products to China.

Technological competition simmers as semiconductors increasingly become the backbone of the modern economy, with a core function in electronic devices and a substantial role in emerging technologies. But how is India, which began its semiconductor journey in the 1970s, placed in this power matrix? How advanced is indigenous manufacturing? And what are the government’s policies to help refine the country’s technology?

Before we explore such questions, let’s take a brief look at chips and their various applications.

Which semiconductor is better?

An iPhone 6 costing over Rs 60,000 in 2014 was 120 million times faster than the Rs 29 crore computer used for the Apollo moon landing of 1969. That’s the magic of semiconductors; doubling the number of components that can fit on a chip while also driving down costs every two years.

Semiconductors are materials that have electrical conductivity between that of a conductor (such as a copper wire) and an insulator (like a rubber glove). This unique property makes them ideal for use in electronic devices. They are typically made of silicon, although other materials like germanium and gallium arsenide can also be used.

Inside all electronic equipment, there is a board amassing a bunch of other components, which can be broadly classified as active and passive. The active components are inside that package and are integrated circuits, or ICs – the brains of the device and also known as chips. They are made from a thin slice or wafer of semiconductor material, usually silicon, that is cut into a small, flat piece. And the capabilities of a chip depend on how many components can be integrated into it.

Semiconductor technology is measured in generations, called process nodes, which are defined by the minimum feature size – or the smallest physical size possible for structures on a wafer – in nanometers. Popular process nodes include 40nm, 28nm, 16nm, 5nm, and 3nm. As the feature size decreases, the scope rises for the number of components as well as performance.

Why are they critical for India?

The focus on the semiconductor industry can be attributed to a recent global shortage which has impacted several industries, including automotive, consumer electronics, and telecommunications.

But there are several other factors to explain its significance beyond this demand-supply binary. Let’s look at what makes it critical for India.

Firstly, the country’s economic growth. India currently imports about 80 percent of its required semiconductors, and the failure to develop a domestic semiconductor industry could add $95 billion to the country’s import bill and widen its current account deficit.

Creating a robust semiconductor industry in India would offer significant job creation opportunities.  The Indian IT industry today contributes $150 billion to the $1 trillion global IT market,  and provides around 5.8 million high-quality jobs in the country – around one fifth of the world’s semiconductor design engineers are from India.

The global semiconductor market is projected to reach over $1 trillion by 2030, up from a market size of $590 billion in 2021, according to a McKinsey report. India’s semiconductor market, meanwhile, is forecast to grow from $15 billion in 2020 to $110 billion in 2030, putting it among the world’s fastest-growing semiconductor markets. To put these numbers in perspective, the Indian government’s estimated budget for the sector in 2023 is $550 billion.

Additionally, semiconductors have a key role in the emerging security state, particularly in military equipment, communication systems, and satellites. In contemporary warfare, the availability and sophistication of equipment often play a more crucial role than the sheer number or skill of military personnel.

For example, in an air battle, aircraft radar is used to track targets that are hundreds of kilometres away. (Yes, a pilot aiming at targets is almost passe). In a melee between two aircraft, the one whose radar can efficiently track more targets is likely to win – a strategic advantage made possible by semiconductors.

The emerging technologies in the field of artificial intelligence and quantum computing also heavily use semiconductors.

While AI systems rely on semiconductor-based components such as central processing units and graphics processing units to perform complex calculations, building functional quantum computers requires precise control over quantum states, which is only possible using semiconductor-based devices.

If India fails to develop advanced semiconductor design and manufacturing capability, the country may have to depend on semiconductor leaders to harness such technologies to their full potential.

How is Indian chip manufacturing positioned?

The electronics industry in India has seen remarkable growth in recent years, fueled by the government's focus on digitalisation, the Make in India initiative, and the rising demand for electronic equipment. The country is now the world's second-largest producer of mobile phones, positioned closely behind China, and a leading manufacturer of other electronic devices like LED televisions, laptops, and tablets.

But when it comes to semiconductor manufacturing, India lacks a robust manufacturing ecosystem and its semiconductor industry primarily focuses on the design and development of products, rather than their production.

Semiconductor design involves creating the blueprint or layout of a semiconductor chip, which includes specifying its functions and characteristics. Design engineers use specialised software tools and simulation techniques to develop the design and verify its performance. The primary goal of semiconductor design is to create a chip that meets the desired specifications and performs its intended functions efficiently.

On the other hand, semiconductor manufacturing involves the physical creation of the semiconductor chip based on the design specifications. This process typically involves several steps, including wafer fabrication, photolithography, etching, deposition, and packaging. Manufacturing engineers use specialised equipment and techniques to transform the design into a physical product. The primary goal of semiconductor manufacturing is to produce a high-quality product that meets the design specifications and is cost-effective for production in large volumes.
